Middle Speed Fully Automatic Paper Plate Making Machine With Photocell Detection Function

Ask Lasest Price
Brand Name :	Mingyuan
Model Number :	ZDJ-400K
Certification :	CE, SGS
Price :	Negotiate
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	150 sets each Yeah
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

Middle Speed Fully Automatic Paper Plate Making Machine With Photocell Detection Function

Middle Speed Fully Automatic Paper Plate Making Machine With Photocell Detection Function

Quick Details

Paper Plate Size	3-11 inch (mould exchangable), Bigger or specially available
Productivity	70-100 Pcs/min
Warranty	1 years
Usage	Round Plate or other shape plate
after-sales service	Engineers available to service machinery overseas

Description

ZDJ-400K High Speed Paper Plate Forming Machine is developed and designed as the requirement of market. It is Pneumatic Type automatic paper plate forming machine with owned unique intellectual property right, which has functions as automatic paper feeding, forming, dish ejecting, temperature constant controlling, automatic counting, fast working speed, safe operation and easy maintenance, etc.

This machine have two working station, two molds installed in the machine, you can produce two sizes paper plates in the same time or let the two molds the same to get double speed. Air compressor is demanded in this machine to offer the air pressure.

Specification

Model	ZDJ-400K
Paper Plate Size	3-11 inch (mold exchangeable)
Raw Material	180-500g/m2 Paper/paperboard, aluminum foil coated paper, one side PE coated paper or other
Rated Productivity	70-100 piece/minute (total two working stations)
Power Source	220V 50Hz or other required
Working Air Source	Air Pressure: 0.8mpa, Air Out-put : 1.5 m³/minute(Need to buy An air compressor)
Total Power	3Kw
Dimension	1480×1150×2050 mm
Weight	500kg

Advantage

Capacity	70-100pcs/min(two positions)
Mold Installed Pic 1	two free molds are installed
Air Cylinder Pic 2	our machine use much more stronger air cylinder than others, which makes the mold pressing more stable and keep the plates shaped
Paper Clamping Manipulator Pic 3	The paper plate machine is using the automatic paper clamping manipulater system, which save a lot of time and labor costs
Total Power	Smaller than other company machine, which saves a lot of electric power without affecting the plates shaping
Free Spare Parts Pic 4	one year guarantee,will give spare parts with machine while packing (enough for 2 year using) with one year,all parts given for free, after that we need charges and delivery cost

Sample Show
