Three Phase Paper Tea Cup Making Machine , Disposable Tea Cup Machine 50HZ 5KW

Ask Lasest Price
Brand Name :	Mingyuan
Model Number :	JBZ-X12
Certification :	CE
Price :	Negotiation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union
Supply Ability :	30 Sets each Month
Delivery Time :	35 - 40 days

Add to Cart

Product Details
Company Profile

Three Phase Paper Tea Cup Making Machine , Disposable Tea Cup Machine 50HZ 5KW

Three Phase Paper Tea Cup Making Machine , Disposable Tea Cup Machine 50HZ 5KW

Quick Details

Type	High Speed Paper Cup Machine
Applications	Fast Forming Paper Coffee Cup, Juice Cup, Ice Cream Cup
Raw Material	PE Coated Paper, Cardboard Paper
Paper Cup Size	3oz-12oz (mold exchangeable), Bigger Cup size need custom Produce Machine
Production Capacity	60 to 75 Pcs / Min
Packaging detail	Plywood case is the usual exporting packing , also can packing according to the customer's requirements
Delivery Time	35days after got Your down payment
after-sales service: Free training, Engineers available to service machinery overseas

Description

This high speed used paper cup machine is a multi station automatic machine producing both single and double PE coated drink cups, ice cream cups through continuous process of automatic paper feeding, sealing, oil injection, bottom cutting, heating, knurling, curling and stacking.

The high speed paper cup machine adopting hot air system, PLC control, servo motor driving, full-automatic failure warning, counting, detection, stopping, etc.

Features

1, Different from other paper cup machine, use special steel heavy

and good quality,much stably when running.

2, Itelligent design,PLC automatic control,servo motor driving,fullautomatic failure

warning,counting,detection,stopping etc(optional)

A, the main motor use the best gear reduction unit;

B, two times bottom paper feeding

C, operate panel use toch screen controlled.

3, Adopt full-automatic sealed lubricating system,which ensures the

long-term uninterrupted high speed running of the machine

4, The parts all adopt standard production,have high generality and good exchange

performance,and facilitate euipment maintenance.

5, all of our cams are nitrided.have high hardness and wear resistant strongly,make sure you use long time.

6, Pendulum using plug-in and link widened to improve the stability;

7, Feed cam is independent, so can be more flexible to adjust for changes in the size of the cup.

Specification

Model	JBZ-X12 high speed paper cup machine
Paper Cup Size	3oz-12oz (mold exchangeable)
Raw Material	One-side PE (polyethylene) film coated / laminated paper Ultrasonic machine can be produce single and double pe paper
Suitable paper weight	180-300 gsm
Productivity	60-75 pcs/ minute
Power Source	220V/380V 50Hz or other required
Total Power	3.3KW
Total Weight	2300KGS
Package Size(L x W x H)	2600x1200x1850mm
Working Air Source	0.4 Mpa, Air Out-put:0.6 m³/minute
Making Double PE coated paper cups, need to buy an air compressor

Loading Paper Cup Machine
