High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min

    Buy cheap High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min from wholesalers

    Buy cheap High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min from wholesalers
    • Buy cheap High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min from wholesalers

    High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min

    Ask Lasest Price
    Brand Name : Mingyuan
    Model Number : MY-500
    Certification : CE
    Price : Negotiation
    Payment Terms : L/C, T/T, MoneyGram, Western Union
    Supply Ability : 25 Sets Each Month
    Delivery Time : 15 days after received client deposit or Open LC
    • Product Details
    • Company Profile

    High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min

    High Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min


    POF Film Shrink Wrap Machine Technical Specification:


    Technical DataHigh Speed POF Film Shrink Wrap Machine For Books 15 - 35 Packs / Min
    Sealing typeL-sealing
    Power supply380V/50-60Hz/3phase
    Packing capacity15 - 35 packs/min
    L-bar sealing size570x480 mm
    Sealing height150 mm
    Product sizewidth + height < 400mm, length + height < 480mm
    Film typecenter-folded polyolefin (POF) film
    Max film size530mm (width) x 280mm(outer diameter)
    Oven size1200(L) x 450(W) x 220(H) mm
    Shrink tunnel conveyor speedvariable, max. 40 m/min
    Shrink tunnel conveyorrotating silicon coated rods
    Power consumptionmax. 8.5 kW
    Working height780-850 mm
    Air pressure0.5MPa (5 bar)
    Main control componentsOmron temperature controller, timer, relay and sensor
    Machine main materialpowder coated carbon steel
    Machine dimension1600 x 770 x 1450mm 1600 x 600 x 1260mm
    Machine weight450kgs

    Machine size pic:

    Service terms:


    Payment term:


    1, 30% T/T in advance (for deposit),the balance should pay before machine loading

    2, 30% T/T in advance (for deposit), 70% do the Irrevocable L/C at sight

    3, 100% do the Irrevocable L/C at sight

    Delivery time &invoice:


    1) Within 30 days from the date of getting deposit of 30%.
    2) Loading port: Shanghai or Ningbo port, China.

    3) Destination port: Port at your option.

    Guarantee terms:


    The seller guarantee the machines are new (or unused) and the guarantee period will be given 12 (twelve) months which starts from the date of the machine's arrival. During this period, the seller will provide free maintenance and free spare parts that caused by the machine's quality, but the buyer must pay the round trip tickets and accommodation expenses for seller's technicians.


    Sample packing by Shrink film wrapping machine:
